IP66 High Speed Linear Actuator
Model: PA-ST1
The PA-ST1 is a high speed linear actuator traveling up to 5.9"/sec with 56 lbs of dynamic force, in a slim tubular body. IP66 sealing keeps this fast linear actuator running in outdoor and agricultural settings.
Couldn't load pickup availability
Overview
[PA-ST1]
The PA-ST1 High-Speed Linear Actuator is designed for applications that require fast linear motion in a compact tubular form factor. Available in 12 VDC configurations with stroke lengths from 1" to 24", the PA-ST1 delivers up to 56 lbs of dynamic force and 225 lbs of static holding force while reaching speeds of up to 5.9"/sec at no load. Its IP66 ingress protection rating provides dependable protection against dust and water exposure for outdoor and demanding automation environments.
Technology
Specifications
The PA-ST1 High-Speed Linear Actuator combines fast travel, compact tubular construction, and durable environmental protection for applications where speed and space efficiency are important. With a full-load current draw of 9.5 A and off-the-shelf stroke options from 1" to 24", this high-speed electric linear actuator is suitable for outdoor use cases, DIY projects, agricultural applications, and home automation.
| Voltage | 12 VDC |
| Dynamic Force | 56 lbs |
| Static Force | 225 lbs |
| Speed - No Load | 5.90"/sec |
| Speed - Full Load | 4.72"/sec |
| Current - No Load | 1.8 A |
| Current - Full Load | 9.5 A |
The PA-ST1 High-Speed Linear Actuator is designed for straightforward integration into systems that require rapid motion in a compact package. Its tubular form factor, 12 VDC operation, IP66-rated construction, and multiple stroke options support reliable installation across a wide range of outdoor and automation projects. Refer to the Product Specifications table for dimensions, duty cycle, environmental rating, connector type, materials, stroke range, and other technical specifications.
Complete your PA-ST1 High-Speed Linear Actuator system with compatible mounting and control components. Refer to the compatibility tables to identify accessories suitable for your selected actuator configuration.
MOUNTING BRACKETS:
The PA-ST1 High-Speed Linear Actuator is compatible with the BRK-09 mounting bracket, providing a straightforward mounting solution for the actuator. Refer to the corresponding product page for additional specifications and installation information.
CONTROL SYSTEMS:
The PA-ST1 draws up to 9.5 A at full load and can be integrated with compatible Progressive Automations control systems that meet the required voltage and current ratings. Refer to the compatibility tables to select the appropriate controller and supporting components for your application.
